General Detail
Steel-Layered Fiber Patch Cable can be used directly in various harsh environments without additional protection. This cable can save
space, reduce construction costs, and make maintenance easier. In addition, the stainless steel tube prevents
damage to the optical fibers, enhancing the safety and stability of the system.
- Product Features
- Product Specification
• Suitable for SMF or MMF cables
• 100% tested and individually packaged
• Steel-layered design for better protection
• Low insertion and high return loss
• Different core options available
• Excellent interchangeability
Insertion Loss | Single Mode PC ≤ 0.2dB |
Single mode APC ≤ 0.2dB | |
Multi mode PC ≤ 0.2dB | |
Return Loss | Single Mode PC ≥ 55 dB |
Single mode APC ≥75 dB | |
Multi mode PC ≥75 dB | |
Storage Temperature | Single Mode PC -40ºC to +90ºC |
APC mode tunggal -40ºC hingga +90ºC | |
Multi mode PC -40ºC to +90ºC | |
Working Temperature | Single Mode PC -40ºC to +85ºC |
Single mode APC -40ºC to +85ºC | |
Multi mode PC -40ºC to +85ºC | |
Repeatability of IL | ≤0,1dB |
