General Detail
FC Fiber Optic Connector is comprised of a Nickel plated Brass body and a Ceramic ferrule/spring/crimp barrel assembly plus a crimp over sleeve and rubber boot. This connector has a screw thread ting into the adaptor to provide a secure connection and is suitable for 900um, 2-3mm cable. The connector is precision made and manufactured to demanding specifications. The combination of a Ceramic ferrule with precision Nickel plated Brass housing provides consistent long-term mechanical and optical performance. The FC connector is available in single mode UPC and APC versions as well as multimode.
- Product Features
- Product Specification
- Factory-installed fiber stub.
- No epoxy and polishing required, No special tools needed when installed.
- Allows up to three re-termination result.
- Easily installed, Quick and easy fiber termination in the field.
- Only 30 seconds needed to learn the process of installation and making.
- Cost effective, Warranty: Two year.
- Fast connecting and repeat, No special tools needed when installed.
- Can be made on-site without splicing connectors.
- Eliminates cable excess length and pigtail splice storage.
- Can be installed and made repeatedly thus avoiding loss.
| Material | ABS |
| Dimensions | 57 x 8 x 8 mm |
| Insertion Loss | <0.3dB |
| Return Loss | >50dB |
| Fiber | 2.0 * 3.0 Bow-type drop cables for access network / 2.0 * 3.0 GJXH |
| Tension | 20N |
| Temperature | Alteration Ratio:<0.5dB |
