General Detail
The MPO/MTP Fan-out Assembly is designed for high-density applications that require high performance and fast installation.
The MPO/MTP fan-out assembly is numbered for full traceability. Available in 12-core configurations, this space-saving assembly is equipped with either an MTP Male or MTP Female Connector on one end and an LC, SC, FC, or MT-RJ Connector on the other end.
This assembly is available in lengths of 10, 20, 30 meters, with custom lengths available upon request. The assembly is available in fiber ribbon configurations of 4, 6, 8, or 12.
- Product Features
- Product Specification
• Plug and Play
• Transition from Trunk Backbone to Fiber Rack
• 12 Core Configuration (Custom Order Options)
• Space Reduction of 65 – 75% compared to traditional Patch Cords
• MPO Fan-out is numbered for traceability
• Test Report with each assembly
| Mating Cycles Delta IL | < 0.2 dB a fiber 500 mating cycles |
| Fiber Cable Type | Single mode: G652D or G657A; Multi mode: OM1, OM2, OM3; |
| Cable Color | Yellow for SM G652 and G657A fiber; |
| Orange for MM OM1 and OM2 fiber; | |
| Aqua for MM OM3 fiber; | |
| Cable Jacket | Ribbon / Fan-out (LSZH / PVC) |
| Patch Cord Pull-out Force | 5N |
| Operating Temperature | -20°C~+70°C |
| Storage Temperature | -40°C~+80°C |
