General Detail
The battery lasts more than 300 hours. Maximum test range + 26dBm. High stability design, no power meter zero operation, improve the test efficiency. Up to ten calibration wavelengths: 830 nm, 850 nm, 980 nm, 1300 nm, 1310 nm, 1450 nm, 1490 nm, 1550 nm, 1590nm, 1625nm. Automatic wavelength recognition function. Automatic loss test function. Year accuracy assurance and recommended measurement cycle.
- Product Features
- Product Specification
- Self calibration by user himself
- Rechargeable lithium battery supports continuous work for up to 48 hours
- Linear indicators (mW) and non-linear indicators (dBm) display in one screen
- Unique FC/SC/ST universal port no complex conversion
- Optional auto power-o ability
| Type of probe | InGaAs |
| Range of wave length | 800~1700 |
| Uncertainty | ±5% |
| Standard wave length (nm) | 850,980,1300,1310,1490,1550 |
| Resolution | Linear indication: 0.1% Logarithmic indication: 0.01dBm |
| Working temperature (°C) | -10~+60 |
| Storage temperature(°C) | -25~+70 |
| Auto power-off time (min) | 10 |
| Continuous working hours | At least 48 hours |
| Dimensions (mm) | 190×100×48 |
| Power supply | Rechargeable lithium battery |
